For contrasting markings to be detected larger than 2 mm
When you want to implement the probe in a complex but known mechanical environment.
Recommendations:
- Consider end clamping and vibration damping fixtures
- Above 1 meter in length, over-sheathing is required (Ref. SURG)
Optical fibre-bundle probe
Operating mode proximity
Reading head oriented in two half-moons
Rigid & Resistant
Factory conformed on a 2.1 mm portion of the probe
The conformation is carried out in our workshops on request according to your indications or plan to be downloaded and filled in.
The connection of the 2 fibre channels is 6 mm diameter.
